Safety instructions for guiding device of combustion air Another end is fastened with ribbon to prevent shaking and falling. The installation components contain a Flexible combustion air hose and the inner diameter is 25mm.Īccording to the installation conditions, the length of combustion air duct may be shortened to 30cm or prolonged to 1m at most.įasten the combustion air duct on heater with hose clamp. Installation of combustion air duct and exhausting device Reinforcement plate (used when necessary).In addition, check whether the ventilation wheels operate freely Be sure to reserve a space between heater and vehicle bottom.Horizontally fasten the heater on vehicle wall. The mounting face of heater legs should be flat.
The holes used to process waste gas, combustion air and fuel pipe. (Exhaust pipe position, the ignition plug is upward). According to different installation conditions, the heater may incline 30°(the flowing direction is downward) at most or rotate 90 around the long axis.
DOWNLOAD AIR COOLER AND HEATER MANUAL FREE INSTALL
The heater is located under the counter.The heater is located between driver’s seat and copilot seat.The heater may also be fastened on the vehicle bottom, but it should prevent the water spraying. Within the limousine, the heater is mainly installed in the room or luggage. The heater is located under the back seat.The heater is located under the undersurface.The heater is located between driver’s seat and co-pilot seat.The heater is located in the front of co-pilot.If unable, the heater may be fastened under the vehicle, but we should note the water spraying. In car/large car, the heater mainly is installed in the vehicle’s passenger room or luggage. The heater is located at the back of driver’s seat.The heater is located at the back wall of driving cab.The heater is located at the foot of co-pilot.If it is impossible to install in the driving cab, the heater may be installed in the toolbox or container. Within the truck, the heater will be installed in the driving cab. (The suggested installation position and methods are shown as follows). When installing the heater, enough operation space should be reserved in the air inlet and the place to dismantle ignition plug and controller. Other dimensions are the same with the overall dimensions of XL-AIRD5.įasten the heater on the bottom of vehicle or the vehicle wall with four screws on the stand bar of heater. The above figure shows the product dimensions of XL-AIRD5.It is used in the minimum installation distance to draw the heating air.It is used in minimum installation space to open cover, dismantle ignition plug and controller. Product informationĬomplete sets of equipment and installation components of heater The inlet pipeline should be protected with safety fence or other proper tools. The heating air which is supplied should be composed by the fresh air or cycled air and be drawn from a clean area. In the working process off heater, it is not allowed to stop heater by powering off.If the fuels flow (disclose) out of the fuel system of the heating equipment, it should be immediately returned to the service provider for maintenance.The heater should be closed when fueling.It is not allowed to use heaters in the place where the Flammable vapor or dust may produce.It is only allowed to use the original accessories and fittings during the installation or maintenance.Go against the specifications specified in the instructions during the installation or operation.Use the parts of other manufacturers without the company’s permission.The following measures should not be taken. Safety instructions for installation and operation When placing the exhaust pipe, we should note that the outlet of exhaust pipe should avoid the combustibles and prevent heating or burning the ground combustibles or loading cargos. When the hot air pipeline is placed in the automobile, it should ensure that it is difficult to be contacted and prevent the personnel or materials from damages. When installing the air inlet, note that it should not be blocked by other materials. When the discharge outlet of exhaust gas is placed, it should prevent the waste gas entering the automobile through the ventilation device, inlet of hot air or window.ĭo not breathe the combustion air used in heater combustion from the passenger compartment.
